380RS Price and Specs 380RS Major Items Listing

Price/color chart
Major specs

Fairlady Z Version NISMO Type 380RS Major Items Listing

Model
Items
2WD
Fairlady Z
Version NISMO Type 380RS
•Engine model VQ35HR (3.8L modified specs)
•Base vehicle name Nissan CBA-Z33
•Operational type
  6-speed manual
•Dimensions
mm
  LxWxH
4420×1840×1305
mm
  Interior dimensions LxWxH
1005×1480×1100
mm
  Wheelbase
2650
mm
  Tread front/rear
1535 / 1545
mm
  Ground clearance
110
•Vehicle weight/passengers
kg
  Empty vehicle weight
1510
  Passengers 2
kg
  Vehicle gross weight
1620
•Performance
m
  Minimum turning radius
5.4
•Equipment
  Drive Rear-wheel drive (FR)
  Steering gear Power assisted rack and pinion
  Suspension front/rear Multi-link/multi-link
  Main brakes front/rear Bench-rated disc/bench-rated disc
  Parking brake front/rear Mechanical rear two-wheel braking
  Tires front/rear 245/40R18 93W•275/35R19 96W

Fairlady Z Version NISMO Type 380RS Engine Major Items

Engine model VQ35HR (3.8L modified specs)
Kind/number of cylinders DOHC V6
mm
Cylinder bore x stroke
95.5×88.4
L
Displacement
3.798
Compression ratio 12.4
kW(PS)/rpm
Maximum output
257(350)/7200
N•m(kgm)/rpm
Maximum torque
397(40.5)/4800
Fuel feed system Nissan EGI (ECCS)
L
Fuel/tank volume
Unleaded premium/80

Please use only the designated fuel in this vehicle. Use of fuels other than that specified may result in malfunction. Please note that malfunctions caused by the use of fuels other than that specified will void the warranty.

•Engine outputs shown are all net values. Engine output indications can be given in both net or gross values. Gross values are those for the engine operating alone. With the same gasoline engine, the net value will be approximately 15% lower than the gross value (in studies by the Japan Automotive Manufacturers Association Inc.).
•Please use unleaded premium gasoline in this vehicle.

A note on the SI international units standards concerning engine output and torque
The previously used engine output unit of PS is now expressed as kW (kilowatts), while engine torque, previously described in kgm, is now N•m (Newton-meters) under SI. Previous figures are expressed in SI as follows, with decimal points rounded up:
1PS=0.7355kW 1kgm=9.80665N・m

Gear ratio/final reduction gear ratio

Transmission 6-speed manual
Engine VQ35HR (3.8L modified specs)
1
Gear ratio
3.794
2
Total engine displacement
2.324
3
1.624
4
1.271
5
1.000
6
0.794
Reverse
3.446
Final reduction gear ratio 3.538
